HP-P6A_Shenzhen Hpled Optoelectronics Co., Ltd

HP-P6A

Working long time without the fault

Energy Saving-- Using the high brightness LED with low power consumption

Macromolecular flexible mask with glareless surface and better contrast ratio

Easy installation and maintenance

Item	HP-P601
Pitch	6mm
Density	27777
Pixel configuration	1R1G1B
Module Size	192mm*192mm
Module Resolution	32*32
Driving method	Constant driving
Cabinet Siz	960mm*960mm
cabinet Resolution	160*160
Screen thickness	180cm
Weight	45kg
Brightness	1500cd
Brightness adjust way	4096
Viewing Distance	16.7M
Refresh rate	≥1200HZ
Repetition frequency	60HZ
Brightness adjustment	256
Power Consumption(Maximum)	220V/AC
Maximum power	700W/m²
Average power	250W/m²
work environment	Indoor
Temperature Range(Operating): / humidity range	-20°～+40°/10%～90%
Life time	50000-100000
Signal	HDMI、CVBS、VGA、YC、DVI、RGB

Indoor LED Display
