HP-P10A

Solid-- Resist all the weathers,IP65

Reliability-- Working long time without the fault

Energy Saving-- Using the high brightness LED with low power consumption

Macromolecular flexible mask with glareless surface and better contrast ratio

Item	HP-P10B
Pitch	10mm
Density	10000
Pixel configuration	1R1G1B
Module Size	160mm*160mm
Module Resolution	16*16
Driving method	Constant driving
Cabinet Siz	960mm*960mm
cabinet Resolution	96*96
Screen thickness	180cm
Weight	53kg
Brightness	6000cd
Brightness adjust way	4096
Viewing Distance	16.7M
Refresh rate	≥1200HZ
Repetition frequency	60HZ
Brightness adjustment	256
Power Consumption(Maximum)	220V/AC
Maximum power	1000W/m²
Average power	350W/m²
Protection Rating:	IP54/IP65
work environment	Outdoor
Temperature Range(Operating): / humidity range	-20°～+40°/10%～90%
Life time	50000-100000
Signal	HDMI、CVBS、VGA、YC、DVI、RGB
